ZOOMLION
25t Truck Crane ZTC250V532-2

25t Truck Crane ZTC250V532-2

ZOOMLION 25-ton truck cranes have a five-section, 41 m main boom. When their boom is fully extended, they can lift up to 6.8 tons and deliver a maximum lifting moment of 734 kN·m. These mobile cranes can move quickly between job sites and handle lifts at different heights and working radii, including work that requires precise load placement.

  • Rated lifting capacity: 25 t
  • Max. load moment with basic boom: 1098 kN·m
  • Max. lifting height with jib: 49.5 m
Request A Quote
Download Brochure
Typical Applications
  • Municipal projects in urban areas with narrow streets or limited space
  • Power line construction in mountainous, hilly, and remote outdoor areas
  • Indoor lifting work in small and midsize factory buildings
  • Infrastructure projects in both urban and rural areas
Features
  • Adaptable to Different Conditions
    Their 19° approach angle and 43% gradeability help these ZOOMLION truck cranes handle different road and site conditions. The idle speed can be adjusted to match the altitude and conditions at the job site.
  • Smooth, Precise Lifting
    The high-displacement, high-pressure variable-displacement piston pump, 3.0 integrated hydraulic system, and self-compensating boom luffing balance valve support smooth operation when several crane functions are used together. The controls respond quickly and allow fine adjustments when positioning a load.
  • Fuel Use and Cab Comfort
    Fuel consumption is 26 L/100 km while driving and 2.6 L/h during crane operation. The driver’s cab has a sleeper berth, and the spacious operator’s cab features a front push-out window and a 7-inch color touchscreen for the load moment limiter.
Technical Specifications
Item Unit Value
Max. Rated lifting capacity t 25
Max. lifting moment with basic boom kN·m 1098
Max. lifting moment of fully extended main boom kN·m 734
Fully extended boom length m 41
Max. hoisting speed of single rope (main winch/auxiliary winch) m/min 120
Max. driving speed km/h 85
Deadweight in working condition kg 31200
Overall dimensions (L × W × H) mm 12750 × 2550 × 3620
Outrigger spread (L × W) m 5.53 × 6.4
Rated power/RPM kW/rpm 199/2300
Max. output torque/RPM N·m/rpm 1050/1700
