ZOOMLION
DL2004 Hybrid Tractor

DL2004 Hybrid Tractor

Designed for a broad range of agricultural and utility operations, ZOOMLION's multipurpose hybrid tractor serves small and medium-sized farms, family farms, livestock farms, forestry work and municipal projects. Combining a diesel-electric hybrid powertrain with continuously variable travel speed control, the agricultural tractor accommodates different working speeds and operating requirements. Front loading, front hitch and front power take-off (PTO) capabilities, together with ISOBUS implement compatibility, extend its versatility across field and utility applications.

  • Emission standard: Euro V
  • Horsepower: 200 HP
  • Fuel tank capacity: 322 L
  • Transmission type: ECVT
Request A Quote
Features
  • Diesel-electric hybrid drive and smooth starting
    The dual-motor coupled diesel-electric hybrid drive combines engine and electric power for fuel-efficient operation. During startup, the tractor uses a range-extender operating mode with direct electric motor drive, allowing the tractor to move off smoothly without abrupt power transitions. The engine meets the Euro V emission standard.
  • Stepless speed control and versatile implement compatibility
    The ECVT transmission provides continuously adjustable travel speeds from 0 to 40 km/h, allowing operators to match travel speed to fieldwork requirements. Front loading capability, a front hitch and a front PTO broaden the range of agricultural and utility operations. The tractor also supports mainstream ISOBUS-compatible implements for standardized communication and control.
  • Integrated controls and improved operating visibility
    The electronic multifunction armrest brings together powertrain, hitch and lighting controls for convenient access during operation. LED work lights arranged around the cab provide 360° lighting coverage for nighttime work, while high-definition cameras at the front of the hood and rear of the cab assist with implement attachment and visibility around the tractor.
  • Operator comfort for extended working hours
    A wide-cushion air-suspension swivel seat provides a more comfortable working position during prolonged operations. By combining a swiveling seat with conveniently positioned armrest controls, the cab layout helps operators manage different tasks without unnecessary movement and reduces fatigue during long working periods.
Technical Parameters
Engine
Model / YCA07200-S500
Engine type / 6-cylinder, high-pressure common rail, turbocharged and intercooled
Fuel tank capacity L 322
New Energy System
Rated motor power kW 120
Rated voltage V 600
Rated high-voltage battery energy kW·h 6.23
Transmission System
Transmission type / ECVT
Speed range km/h 0-40
Drive system / Dual-motor coupled drive (2-speed AMT)
Min. turning radius m 5.4
Hydraulic System
Output flow L/min 150
Hydraulic remotes set 5 sets
Hitch System
Hitch type & category / Category 3
Max. lift capacity (at 610 mm) kN 56.5
Power Take-Off (PTO)
PTO speed r/min 540/540E/1000
Brake System
Air brake / Dual-circuit air brake
Weight
Max. operating weight kg 12000
Dimensions
Overall dimensions (L × W × H) mm 5376×2550×3300
Wheelbase mm 2850
Track width (front / rear) mm 1907/1840
Ground clearance mm 450 (at drawbar)
Tires & Wheels
Tire size (front / rear) Standard: front 600/65 R28 / rear 710/70 R38
