130t Rough Terrain Crane ZRT1300V532

130t Rough Terrain Crane ZRT1300V532

ZOOMLION 130-ton rough-terrain cranes can lift heavy equipment in large oil and gas fields, open-pit mines, chemical industrial parks, and water infrastructure projects. Their two-axle rough-terrain chassis allows them to move across muddy and gravel-covered sites, particularly where heavy loads require lifting with the boom at a shorter length.

  • Max. rated lifting capacity × working radius: 130000 × 2.5 kg·m
  • Max. load moment with basic boom: 3760 kN·m
  • Max. lifting height with jib: 66.7 m
Request A Quote
Download Brochure
Typical Applications
  • Heavy equipment lifting in large oil and gas fields
  • Equipment installation and maintenance in open-pit mines
  • Heavy lifting in chemical industrial parks
  • Construction of water management infrastructure
  • Lifting heavy equipment with the boom at a shorter length on muddy or gravel-covered worksites
Features
  • The five-section, U-shaped main boom extends to 50 m for lifts at different heights and working radii, while the maximum load moment with the basic boom is 3,760 kN·m.
  • These ZOOMLION rough-terrain cranes can travel at up to 30 km/h and have a maximum gradeability of 75%, so they can move between lifting locations over slopes and unpaved roads.
  • Operators can use a remote control to extend and retract the outriggers during setup. The outrigger position detection and configuration recognition functions help them check that the outrigger positions match the selected lifting configuration.
  • Standard cameras help operators see the surrounding area, while seat ventilation and lower-back support make long hours in the cab more comfortable.
Technical Specifications
Item Unit Value
Max. Rated lifting capacity t 130
Max. lifting moment with basic boom kN·m 3760
Max. lifting moment of fully extended main boom kN·m 1862
Fully extended boom length m 50
Max. hoisting speed of single rope (main winch) m/min 130
Max. driving speed km/h 30
Deadweight in working condition kg 62500
Overall dimensions (L × W × H) mm 15355 × 3400 × 3970
Outrigger spread (L × W) m 8.5 × 8.4
Rated power/RPM kW/rpm 194/2200 (Dongfeng Cummins)
194/2400 (US Cummins)
Max. output torque/RPM N·m/rpm 990/1500
