ZOOMLION
TE100-DH Hybrid Harvester

TE100-DH Hybrid Harvester

Combining engine power with a partial electric-drive system, the ZOOMLION hybrid combine harvester electronically coordinates power delivery and travel speed to improve harvesting efficiency while reducing energy consumption. With a feed capacity of 10 kg/s and a selection of crop-specific headers, the hybrid harvester supports large-scale harvesting of wheat, grain corn, soybeans and other crops.

  • Overall Dimensions (Excluding Header): 6,100 × 2,900 × 3,420 mm
  • Throughput Capacity: 10 kg/s
  • Minimum Ground Clearance: 330 mm
Request A Quote
Features
  • Electronically coordinated hybrid power
    The electronic control system manages the engine, electric drive and travel speed together, helping coordinate power delivery with harvester movement during field operations. This arrangement is reported to improve operating efficiency by 15%.
  • One-touch adjustments and electronic controls
    One-touch speed adjustment for the threshing rotor, reel and cleaning fan allows operators to change key harvesting settings without adjusting each component manually. Rotor anti-blockage protection, electronic gear shifting and an electronic parking brake provide additional operating controls.
  • Partial electric drive with lower energy consumption
    The partial electric-drive hybrid configuration simplifies the transmission structure while providing stable power output. According to the specified performance data, the hybrid drive reduces operating energy consumption by 30%.
Technical Parameters
Machine
Feed rate kg/s 10
Overall dimensions without header (L × W × H) mm 6100×2900×3420
Overall weight without header kg 7400
Ground clearance mm 330
Engine
Model / YCA05190-T300
Number of cylinders cylinders 4
Fuel tank capacity L 440
Threshing & Separation
Rotor type & layout / Single longitudinal rotor (threshing & separation)
Rotor diameter × length mm Ø620×3180
Rotor speed r/min 0–1200 (recommended ≤1000 during operation)
Total separation area m² 2.5
Cleaning system type / Fan-and-sieve type
Grain Tank
Grain tank capacity m³ 3.2
Unloading rate L/s 60
Chassis
Transmission type / Mechanical + motor-driven CVT
Tires (front/rear) / Front 540/70R24 / rear 300/80R15.3
Drive type / 2WD
Header
Rice/wheat rigid header Working width m 2.96/3.25/4
Weight kg 726/785/895
Soybean flex header Working width m 4
Weight kg 1200
Corn header with stalk chopper Rows × row spacing rows × mm 5×700/5×750/4×900
Weight kg 1867/1720/1675
Grain header Rows × row spacing rows × mm 7×410
Weight kg 1100
