DH7-6000 Hybrid Harvester

DH7-6000 Hybrid Harvester

Combining a 353 kW engine with a range-extended hybrid powertrain and dual-motor four-wheel drive, the ZOOMLION hybrid combine harvester provides power for sustained harvesting across large fields while reducing energy consumption. An 11.5 m³ grain tank and 110 L/s unloading rate help minimize interruptions, while intelligent electronic controls and harvesting monitoring support efficient, continuous field operations.

  • Emission standard: Stage V
  • Throughput capacity: 20 kg/s
  • Minimum ground clearance: 460 mm
  • Overall dimensions without header (L × W × H): 10,706 × 4,004 × 4,038 mm
Request A Quote
Features
  • Reliable drivetrain with reduced maintenance
    The hybrid drivetrain uses 70% fewer transmission components, including chains and belts, than conventional diesel-powered models. Fewer mechanical drive components reduce maintenance points, while mean time between failures (MTBF) is improved by 50%.
  • Adaptive harvesting with electronic control
    Real-time monitoring and coordinated adjustment of operating parameters enable the harvester to adapt to changing working conditions, improving operating efficiency by 20%.
  • Stable speed and improved harvesting quality
    The electronic control system maintains stable operating speeds under load, helping improve harvesting quality by 10%.
  • Range-extended hybrid power and four-wheel drive
    The range-extended hybrid system combines engine power with dual-motor four-wheel drive to support sustained, high-intensity harvesting operations.
  • Lower energy consumption
    By incorporating electric drive into the hybrid powertrain, the combine harvester reduces operating energy consumption by more than 30%.
Technical Parameters
Resource No. DH7-6000
018907500H0100001 (Stage V region)
Machine Overall dimensions without header (L × W × H) mm 10706×4004×4038
Overall weight kg 20700(unladen)
Gradeability ° 20
Operating slope capability ° Lateral ±4.5° / longitudinal 12°
Engine Model / YC-K11480
Rated speed r/min 1900
Rated power kW 353
Displacement L 10.98
Emission standard Stage V
Fuel tank capacity L 760
Threshing & Separation Threshing & separation system Triple transverse + dual longitudinal rotors
Threshing channel width mm 1460
Main threshing drum diameter × length mm 600×1440
Main threshing drum speed r/min 330–930
Separation rotor diameter × length mm 445×4200
Separation rotor speed range r/min 360–1050
Concave type / Grate-type
Total separation area m² 3.7
Returns threshing system / Returns elevator to threshing drum
Clean grain elevator cross-section mm 247×228
Cleaning System Cleaning sieve type / Counter-moving dual sieves
Sieve type / Louvered sieve
Total sieve area m² 4.48
Cleaning fan type / Turbine type
Fan diameter mm 400
Fan speed range r/min 640–1660
Straw Chopper Straw chopper configuration / Flail type
Straw chopper quick-change / No
Grain Tank Grain tank capacity m³ 11.5
Unloading height m 4890
Unloading rate L/s 110
Cab Air conditioning (recirculation/fresh air) Recirculation / fresh air
Seat suspension Air suspension
Cab configuration Pressurized cab
Chassis Transmission type / Electronically controlled shifting + motor-driven CVT
Front tires / tracks / IF600/70R28
Rear tires / 900/60 R32
Drive type / 4WD
Travel speed km/h ≤40
Feeder House Feeder house width mm 1356
Feeder house lateral/vertical float 6-way
Feeder house reverser Standard
Intelligent Systems Operator assistance Standard
Forward dynamic obstacle warning Standard
Online harvesting quality monitoring Standard
Grain tank full monitoring Standard
Unloading monitoring Standard
Header height/contour control Standard
Self-diagnostics & OTA remote updates Standard
