TE100 Wheeled Combine Harvester

TE100 Wheeled Combine Harvester

Suitable for harvesting wheat, grain corn, soybeans, rice and other grains, the ZOOMLION axial-flow combine harvester uses a single longitudinal rotor to thresh and separate crops at a feed rate of 10 kg/s. Adjustable rotor speed and concave clearance allow the harvesting process to accommodate different crop conditions, while a 140 kW engine and hydrostatic four-wheel drive support operation in challenging field environments.

  • Drive Type: 4 WD
  • Operating Weight: 7,300 kg
  • Throughput Capacity: 10 kg/s
  • Unloading Rate: 60 L/s
Request A Quote
Features
  • Adjustable threshing for different crops
    The single longitudinal rotor handles threshing and separation, with stepless adjustment of rotor speed and concave clearance to suit the harvesting requirements of different crops.
  • Power and mobility in challenging fields
    A 140 kW Yuchai engine supplies power for harvesting, while hydrostatic four-wheel drive improves mobility across difficult field conditions.
  • Comfort during long harvesting operations
    The enclosed, climate-controlled cab combines heating and air conditioning with a suspension seat and electrically adjustable rearview mirrors to improve operator comfort.
  • Durable structure with reduced maintenance
    High-strength steel plates provide structural strength, while maintenance-free bearings at key locations help reduce maintenance demands during regular harvesting operations.
Technical Parameters
Machine
Feed rate kg/s 10
Overall dimensions without header (L × W × H) mm 6100 × 2900 × 3420
Overall weight without header kg 7300
Ground clearance mm 420
Engine
Model / YCA05190-T300
Number of cylinders cylinders 4
Fuel tank capacity L 440
Threshing & Separation
Rotor type & layout / Single longitudinal rotor (threshing & separation)
Rotor diameter × length mm Ø620 × 3180
Rotor speed r/min 310-1030
Total separation area m² 2.5
Cleaning system type / Fan-and-sieve type
Grain Tank
Grain tank capacity m³ 3.6
Unloading rate L/s 60
Chassis
Transmission type / Mechanical + hydrostatic CVT
Tires (front/rear) / Front 19.5L-24 / rear 380/70R20
Drive type / 4WD
Header
Rice/wheat rigid header Working width m 2.96/3.25/4
Weight kg 726/785/895
Soybean flex header Working width m 4
Weight kg 1200
Corn header with stalk chopper Rows × row spacing rows × mm 5×700/5×750/4×900
Weight kg 1867/1720/1675
Grain header Rows × row spacing rows × mm 7×410
Weight kg 1100
